- Machine Structure & Features
| Bed Construction:
1.This series represents our mature domestic/export product line, featuring compact structure, ergonomic design, high-torque spindle, exceptional rigidity, stable performance, and superior long-term accuracy retention. 2.The optimized head stock design accommodates both disc-type and shaft-type workpiece machining, capable of linear/arc interpolation, metric/imperial threading, and multi-start threading. Ideal for complex geometries and high-precision components. 3.Machine bed and saddle utilize specially formulated hardened guideways with high-frequency quenching, delivering ultra-wear resistance and prolonged accuracy stability. |
2.Technical Specifications
|
Parameter |
Unit |
Value | ||
| CK6186 | ||||
| Swing Over Bed | 毫米 | φ860 | ||
| X-axis Guideway Span | 毫米 | 330 | ||
| Z-axis Guideway Span | 毫米 | 600 | ||
| Max. Turning Diameter | 毫米 | Φ540 | ||
| Max. Machining Length | 毫米 | 3000 | ||
| Distance Between Centers | 3200 | |||
| Maximum Disc-Type Work piece Diameter |
毫米 |
800 |
||
|
Center
Height |
Center Height Above Bed Ways |
毫米 |
430 |
|
| Height from Floor |
毫米 |
1210 |
||
| 主轴 Bore Diameter | 毫米 | φ 105（Optional： φ 130） | ||
| Bar Capacity | 毫米 | φ100/φ125 | ||
| 主轴 Nose | A2-11 | |||
| Chuck Specifications | 毫米 | Standard φ400 3-Jaw Chuck Specifications | ||
| Spindle Taper Specifications | No | Metric120， 1：20 | ||
| Spindle Speed Range | 转速 | 30-84，53-150，125-350，300-835r/min
4-Speed Stepless Transmission within Ranges |
||
| Tail stock Quill Diameter | 毫米 | φ 130 | ||
| Tail stock Quill Taper Specifications |
No |
MT6# |
||
| Tail stock Quill Travel | 毫米 | 265 | |
| Tail stock Type | Manual hand wheel-operated | ||
| Number of Tool Stations on
Electric Turret |
Unite |
4 |
|
| Tool Holder Square Size | 毫米 | □32 ×32 mm (4-station turret) | |
|
Ball screw Models |
X 轴 | FYND4006-3-P3 | |
| Z 轴 | FYND6310-5-P4 | ||
| X/Z-axis Rapid Traverse Speeds |
m/min |
4/5 |
|
| X-axis Travel | 毫米 | 430 | |
| Z-axis Travel | 毫米 | 3000 | |
| Minimum Command Unit | 毫米 | 0.001 | |
| Main 主轴 电机 Power | KW | 15(VF drive) | |
| X/Z- axis Servo Motor Torque Specifications |
N.M |
10/15 |
|
| Total Power Supply Capacity | KW | 30 | |
| Machine Net Weight
(Approximate) |
Kg |
7200 |
|
| 机器尺寸
(L×W×H) |
毫米 |
5450x2000x2000 |
|
Important Notes:
Chuck/Fixture Installation:
Observe the maximum rotational speed limit of the selected chuck or fixture
Power Supply Requirements:
Strict voltage stability is required (±10% tolerance).
A voltage stabilizer must be installed if grid fluctuations exceed this range to
prevent operational failures or unpredictable outcomes.
- Standard Configuration
|
Component |
规格 |
Qty |
品牌 |
起源 |
| 数控系统 | GSK988TDi | 1 set | GSK CNC | 国内 |
| Spindle Motor | 15KW (VF) | 1 set | Nanjing Huanqiu | 国内 |
| Spindle Structural Specifications | Precision assembly | 1 set | Self-made | 国内 |
|
Main shaft bearing |
NN3032K/W33P5;234432M/SP
NN3026K/W33P5 |
1 set |
Tianjin
Nine/Wafangdian |
国内 |
| Guide rail | Hard rail | 1 set | Self-made | 国内 |
|
X-direction ball screw |
FYND4006 |
1 set |
Nanjing aftsman ship |
国内 |
| Z-direction ball
screw |
FYND6310 |
1 set |
Nanjing |
国内 |
| X-direction lead
screw bearing |
BS2562/P4DB;6205 | 1 set | Two-axis | 国内 |
| Z-direction lead
screw bearing |
BS4090/P4TBT;BS4090/P4DT | 1 set | Two-axis | 国内 |
| Knife rest | HAK-21 280 | 1 set | Hongda | 国内 |
| Automatic
lubrication device |
RBCLB-3ZK |
1 set |
国内 |
|
| Four-prong
manual single |
K11 400 |
1 set |
Wafang dian |
国内 |
| Cooling pump | 1 set | 国内 | ||
| Optional： Hydraulic unit | 60L | 1 set | 国内 | |
| Optional： Hydraulic chuck | KT12-3/ KT15-3 | 1 set | 国内 | |
| Center frame | Φ230-420mm | 1 set | 国内 |
4 . Included Documentation & Accessories：
| No. | 项目 | Qty | 备注 |
| 1 | Packing list | 1 | set |
| 2 | Certificate of Conformity (including Precision Inspection sheet) | 1 | set |
| 3 | User Manual | 1 | set |
| 4 | Instruction Manual of Numerical Control System | 1 | set |
| 5 | Instruction Manual for Electric Tool Rest | 1 | set |
| 6 | Frequency Converter Instruction Manual | 1 | set |
| 7 | Motor Instruction Manual | 1 | set |
| 8 | Driver Instruction Manual | 1 | set |
| 9 | Oil Pump Instruction Manual | 1 | set |
